Automatic Strapping Machine
Automatic Horizontal Strapping Machine MH-105A
Automatic Horizontal Strapping Machine MH-105A is a automatic strapping machine in the RDK series. Key specifications: Power supply 380V 50/60Hz 3.1kW; Air pressure (MPa) 0.4-0.6; Machine dimension 1930*3240*2800; Frame size W1500*H1500 (Customized). OEM & ODM customization available.
Specifications
- Power supply
- 380V 50/60Hz 3.1kW
- Air pressure (MPa)
- 0.4-0.6
- Machine dimension (mm)
- 1930*3240*2800
- Frame size (mm)
- W1500*H1500 (Customized)
- Packing speed (sec/cycle)
- <= 15
- PP strap (mm)
- Width 9-15 (±1), thickness 0.55-1.0 (±0.1)
- PP strap spool (mm)
- W160-180, inner dia.200-210, outer dia.400-500
Automatic Horizontal Strapping Machine MH-105A is a automatic strapping machine in the RDK series. Key specifications: Power supply 380V 50/60Hz 3.1kW; Air pressure (MPa) 0.4-0.6; Machine dimension 1930*3240*2800; Frame size W1500*H1500 (Customized). OEM & ODM customization available.
Key Features
Power supply: 380V 50/60Hz 3.1kW
Air pressure (MPa): 0.4-0.6
Machine dimension (mm): 1930*3240*2800
Frame size (mm): W1500*H1500 (Customized)
Technical Specifications
Parameter | Specification |
|---|---|
Power supply | 380V 50/60Hz 3.1kW |
Air pressure (MPa) | 0.4-0.6 |
Machine dimension (mm) | 1930*3240*2800 |
Frame size (mm) | W1500*H1500 (Customized) |
Packing speed (sec/cycle) | <= 15 |
PP strap (mm) | Width 9-15 (±1), thickness 0.55-1.0 (±0.1) |
PP strap spool (mm) | W160-180, inner dia.200-210, outer dia.400-500 |
OEM / ODM
Customized configurations are available according to customer requirements, including frame size, table height and strap specifications.
